Hanyang RS250 With LED light Retro Steet Motorbike

Short Description:

Single cylinder 250cc water cooled Motorcycle


Product Detail

Product Tags

1 (1)
1 (2)
1 (3)
1 (4)
1 (5)
1 (6)
1 (7)
1 (8)
1 (9)

LED

rs2501

Equipped with LED round headlights, it is more compact and elegant. The motorcycle looks shorter and slender.

Tank

14L full tank capacity.

rs2502

ABS

rs2503

Dual channel ABS

Engine

Single cylinder water cooled engine, Delphi EFI. The maximum displacement is: 250cc, the compression ratio is: 10.8:1, the maximum power is: 18.5/8500, the maximum torque is: 23.0/6500, the engine stability is very good.

rs2504

Tubeless tires

rs2505

Tubeless tires. Front wheel tire size is 110*70*16, rear wheel tire size is140*70*16.

Disc brake

Front wheel double disc and rear wheel is single disc brake.

rs2506
rs2507

Seat

Split seat design, soft and breathable, more comfortable for driver and passenger.

rs2508

Size

rs2509

L×w×h is 2000*760*1060mm, seat height is 780mm, wheelbase is 1320mm, maximum speed (km/h) is 120Km/h.

Double throttle line, easy to return.

The single throttle is equipped with a mechanical cable to control the throttle, that is, a steel cable is used to control the opening of the throttle. When the throttle is twisted, the cable will open the throttle intake, and when the throttle is released, it will be closed by the return spring on the throttle. Throttle intake port.

rs25010
rs25011

The return spring plays the role of closing the throttle intake port and returning the throttle cable, but when the return spring is rusted and stuck, the throttle valve is dirty, and the inside of the throttle cable is rusted or stuck due to dust pollution, the throttle valve may be stuck. It cannot be closed or opened normally. If this happens during driving, it is commonly known as the "speeding". The throttle opening is not controlled, which is a very dangerous situation.

At this time, if there is another throttle cable that can control the closing of the throttle valve, of course, the safety factor will be higher than the throttle valve controlled by the single throttle cable.The dual throttle cable is for safety reasons. The two cables control the opening and closing of the throttle valve respectively. Even if the throttle valve spring is rusted and stuck, or the throttle valve is dirty, or one throttle cable is not running smoothly, it will not As a result, the accelerator opening is uncontrolled, and the reason is the same as the dual-circuit braking system on the car, which is equivalent to providing a spare tire.

rs25012

LCD

rs2509

Full LCD display instrument, driving information is clear at a glance.

All stainless steel muffler

All stainless steel muffler, beautiful and durable, strong and powerful sound, feel the passion and heartbeat brought by the surging power.Ground clearance 150MM, high passability, easy to deal with various road conditions.

rs25014

Product Details

Engine
Chassis
Other configuration
Engine
Displacement (ml)  247.5ml
Cylinder(pcs) 1
Stroke ignition  4 stroke
Valves per cylinder (pcs)  4
Valve structure   Overhead single camshaft
Compression ratio  10.8:1
Bore x Stroke (mm)  69*68.2
Maximum power (kw/rpm)  18.5/8500
Maximum torque (N m/rpm) 23.0/6500
Cooling Water
Fuel supply method  EFI
Start   Electric start
Fuel consumption(g/(kW·h)) 340
Gear shift  International 6 gear
Shift Type  Manual
Transmission  Chain drive
Chassis
Length×width×height(mm) 2000*760*1060
Seat height (mm)  780
Ground clearance (mm)  150
Wheelbase (mm)  1320
Total mass (kg)  305
Curb weight (kg)  155
Fuel tank volume (L)  14L
Frame form  hanging
Maximum speed (km/h)  120Km/h
Wheel Aluminum
Tire  (front) 110*70*16
Tire  (rear)  140*70*16
Braking system disc
Brake Technology  Hydraulic Disc
Suspension system  Front inverted hydraulic shock absorber
Other configuration
Instrument  liquid crystal
Lighting   LED
Handle One-piece variable diameter
Battery  12v9A
