Water-cooling V-type double cylinder engine with 8 valves and 6 geart configuration, high displacement with lower vibration noice and fuel consumption.
Upright shock absorber more stable and more comfortable to drive for long journey.
Automotive grade double channel ABS system, guarantee driving safety.
USA Gate belt transmission system make power transmission more efficient, free from soil and dirt, less vibration noise, more convenient in maintenance.
①Full LED equipped, the headlight design is simple with aesthetic characteristics that people pursue.；
②International famous brand LED lights, brightness and service life are guaranteed
③The design of the turn signal lights are with Chinese elements. It is connected between the top two sides of the shock absorber in the front and the brake lights assembly in the rear.
①The instrument panel is LCD full-color, driving information is more comprehensive. With touch form and water resistance.
②The visibility in various weather and different light conditions should also be better.
① We use a typical American handle switch, feels solid.
② It has a dual flashing function. The way to turn it on is to require the owner to press the left and right turn signals at the same time.
①The front and rear disc brakes are with single disc double-piston floating calipers, equipped aluminum alloy wheels, which shows the retro cruising style, and meet the driving requirements of different road conditions.；
②The dual-channel ABS anti-lock system makes the riding safer and more reliable.
③ The up-right front shock absorber is using a famous brand of YuAn, the damping structure is similar to the internal structure of inverted shock absorber. The performance of compression and rebound is infinitely close to the inverted shock absorber driving sense.
①The wheel hub is equipped with cast aluminum alloy wheels, front tier of 130/70-19; rear tier of 240/45R17.The tires are specially customized for XS800N with cruising style. The manufacturer is CST.
①We use panasonic fan with large-capacity and large-flow water tanks, provide powerful heat dissipation even on congested urban roads.；
② Effectively improve the air flow rate and flow rate flowing through the radiator, enhance the heat dissipation capacity of the radiator and cool the engine and accessories to minimize engine power loss；
③Configure a hard plastic water tank cover to effectively protect against the impact of hard objects；
①The belt drive is quiet, almost no maintenance is required, and the comfort of the cruise vehicle is improved. Imported American Gates belts are used.
①The shape of the fuel tank is the classic water drop of an American car, the 13L fuel tank；
②The shape is round, full and atmospheric；
③Automotive-level surface curvature requirements and coating technology, the brightness, hue, and saturation of the perfect color；
①650CC V-shaped two cylinder eight-valve water-cooled engine, the pistons of the cylinders on both sides hedge off inertia when working, reducing the vibration of the vehicle；
②The well-known domestic brand Delphi EFI system is equipped with imported FCC clutch, the clutch strength is moderate, and the power adjustment is smooth；
③The maximum power is 39kW/7000rpm, and the maximum torque is 58N.m/5500rpm, the horsepower is stronger than that of Harley 883.
①The seat is designed to fit the driver's riding, make the riding more confortable；
②The overall shape of the seat is soft, make you have a comfortable riding；
③It is easy to unload, and the two-seats can be quickly switched to the single-seat.
①Yu An well known brand rear shock absorber, can be adjusted precisely, high strength with adjustable spring，
②the 7-stage adjustable resistance has stronger shock absorption performance, can meet different road conditions.
①The muffler is designed as a single side & double outlets snake shape, its voice is thick and loud.
| Displacement (ml) | 650 |
| Cylinders and number | V-type engine double cylinder |
| Stroke ignition | 8 |
| Valves per cylinder (pcs) | 4 |
| Valve structure | overhead camshaft |
| Compression ratio | 10.5:1 |
| Bore x Stroke (mm) | 82X61.5 |
| Maximum power (kw/rpm) | 39/7000 |
| Maximum torque (N m/rpm) | 58/5500 |
| Cooling | WATER COOLING |
| Fuel supply method | EFI |
| Gear shift | 6 |
| Shift Type | FOOT SHIFT |
| Transmission |
| Length×width×height(mm) | 2220X805X1160 |
| Seat height (mm) | 695 |
| Ground clearance (mm) | 160 |
| Wheelbase (mm) | 1520 |
| Total mass (kg) | |
| Curb weight (kg) | 226 |
| Fuel tank volume (L) | 13 |
| Frame form | Double cradle frame |
| Maximum speed (km/h) | 140 |
| Tire (front) | 100/90-ZR19 |
| Tire (rear) | 150/80-ZR16 |
| Braking system | Front/rear caliper hydraulic disc type with double channel ABS |
| Brake Technology | ABS |
| Suspension system | Hydraulic disc type |
| Instrument | TFT LCD SCREEN |
| Lighting | LED |
| Handle | |
| Other configurations | |
| Battery | 12V9Ah |
